*1 Projectors sold in some countries or regions require an ET-NUK10 Upgrade Kit available from PASS to activate NFC function. See NFC Regional Compatibility List for details, *2 Some devices do not support projector autofocus function, *3 When projecting a 300-inch image. Maximum distance is 3 m (10 ft) for a 100-inch image, *4 Requires optional AJ-WM50 Wireless Module.
Remote Preview for a Smooth Start to Your Event
Remote Preview lets projectionists confirm video-signal integrity by viewing thumbnails of the input signal on a laptop prior to projection. Accessed via software or web browser, Remote Preview works with the projector in Standby or with the shutter on. It’s useful at events such as concerts where opportunities to check content on screen are limited due to stage traffic and other logistical factors. Remote Preview reduces chance of errors before the performance, and if an error is detected, helps narrow down the possible cause to the signal.
To simplify setup and streamline operation, PT-RQ35K Series features an Information Monitor near the control panel. The high-visibility screen offers menu navigation via arrow keys and provides a convenient way to configure network settings such as Projector ID without projecting the OSD menu. During operation, it shows projector status including temperature, runtime, error codes, and input signal information.
Compatible with Our 3-Chip DLP Projector Lens Lineup*
Share optional lenses between Panasonic 3-Chip DLP™ projectors in your inventory and the new PT-RQ35K Series projectors. Our lineup of 18 lenses comprises fixed and zoom lenses that adapt to venues of any scale; a groundbreaking ET-D3LEF70 Fisheye Lens for dome projection in planetariums; and the new ET-D3LEU100 Ultra-Short-Throw Lens (0.370:1, WUXGA) and ET-D3LEW200 Short-Throw Zoom Lens (0.645–0.850:1, WUXGA). These glass lenses produce spectacular images from short throw-distances with zero offset (eliminating the gap between the edge of the image and projector’s mounting surface) and are ideal for theme-parks, museums, performance venues, and other experiential applications. Both equip wide-range powered Vertical and Horizontal Lens Shift, while the ET-D3LEW200 increases location flexibility with powered optical zoom.
Red and Blue Lasers for Deep, Accurate Colour
A combination of two blue and one red laser module expands colour-gamut reproduction to 114 %* of the PT-RQ32K with 91 % DCI coverage, saturating the screen in lavish colour and drawing the audience deeper into the artist’s world. Optimized blue-laser wavelengths achieve truer blue while the red laser intensifies red expression for a greater sense of realism.
Dynamic Digital Control for Stable Colour Performance
While red lasers heighten colour expression, their successful implementation has been challenged by inherent sensitivity to temperature fluctuations. Dynamic Digital Control solves the problem by modulating red-laser output frame-by-frame to achieve optimal RGB balance according to colour requirements and operating temperature, which is managed by a discrete cooling system. With stability guaranteed, multiple lasers are free to unleash awesome colour with luxuriant reds and pure blues taking the viewer closer to the artist’s intention.
* In comparison to the PT-RQ32K according to internal research.
Multi-Laser Drive Engine with Failover Redundancy Circuits
Multiple Laser modules are equipped with Panasonic’s unique Failover Circuitry. If a single laser diode fails, only diodes in the affected series are bypassed rather than all of the diodes in the module, as is the case with some competitive laser projectors. Projection continues uninterrupted with imperceptible loss in brightness. Failover Circuitry adds another layer of insurance in situations where image display must be maintained.
Flexible Black-Level Adjustment
Edge-blend uniformity on curved screens is difficult to achieve with line-based black-level border adjustment. Warped image-edges result in unequal blend-widths, and a lack of uniformity in overlapping areas is exposed when dark scenes are projected. PT-RQ35K Series gains new black-level calibration that allows black borders to be reshaped to suit screen curvature using up to 17 control points in much the same way as our Free Grid function. Adjacent images can be matched within a 0.5-dot margin—ideal for 4K video projection—while a wider range of adjustment in finer increments is also enabled.
Backup Input Guarantees Picture Display
When the Backup Input setting is enabled and the source device is configured to output an identical signal to the projector’s primary and secondary input terminals, it can automatically switch between signals in as little as 0.3 seconds whenever the primary signal is interrupted or restored. No screen-blanking occurs when switching. Maintain image display in situations when projection must not be interrupted
