iiyama Prolite TE8612MIS-B1AG

Call for Availability

SKU: F940

This product is now discontinued. Please contact us for details of a replacement product

Interactive display, offering 4K UHD resolution, PureTouch-IR, and easy content sharing with iiyama Share.

  • 400 Candela Brightness
  • 86″ diagonal size
  • 4K UHD Resolution – 16:9 Aspect Ratio
  • 3 Year On SIte warranty
  • 58.6 KG
  • Project pricing available
Call for Price & Availability

Projectorpoint Opinion

The iiyama PROLITE TE8612MIS-B2AG is an 86″ Interactive 4K UHD Touchscreen equipped with a Zero Airgap LCD screen providing a seamless viewing experience. It also features PureTouch-IR, which ensures 1mm touch accuracy for smooth and swift annotation, making it an ideal tool for presentations and educational purposes.

Featuring iiyama Share and EShare app, it allows you to connect up to 9 devices making sharing, streaming, and editing content from your device to your interactive display and vice versa, a breeze. It supports AirPlay, Chromecast and Miracast, making it compatible with a wide range of devices.

In terms of security, the display offers Screen lock and USB passcode protection to ensure user security. It also includes a new Clean app that clears all data after use, ensuring privacy and security for all users.

Manufacturer Overview

PROLITE TE8612MIS-B2AG
86″ Interactive 4K UHD Touchscreen elevating interactive collaboration.
The TE8612MIS-B2AG is an exceptional 4K UHD interactive display designed by iiyama to enhance collaboration, communication, and engagement. With key features like Zero Airgap LCD screen eliminating parallax, accurate PureTouch-IR, iiWare 10 with Android 11, Wifi, and the iiyama DMS (Device management System), this display transforms the way you engage with content, making it an indispensable tool for modern workspaces and educational settings.
Boasting a new 4K Interface with User Profiles for simple login and access to your very own bespoke application and Cloud Drives or harmonise with your existing estate and unleash the true power of Windows and Office applications. iiyama TE8612MIS-B2AG becomes a highly personalised & flexible device within a busy hybrid environment for multiple users.
Share wirelessly more easily than ever before with iiyama Share and EShare app, bringing effortless ideation and efficient collaboration in your enterprise or school. This affordable display transforms the modern workplaces, educational institutions, dynamic meeting spaces and beyond. Elevate your interactive experience with the iiyama TE12 SERIES displays and embrace the future of visual communication.

PURETOUCH-IR
PureTouch-IR from iiyama delivers 1mm touch accuracy for the smoothest and fastest annotation.

IIWARE
iiWare 10 features Note, Browser, Cloud Drive and the option for you to side-load relevant apps you require for your organisation.

IIYAMA SHARE
Connect up to 9 devices and easily share, stream and edit content from your device to your interactive display and vice versa, back to your laptop, tablet or phone. iiyama Share supports AirPlay, Chromecast and Miracast.

IIYAMA DMS
This software provides organisations a suitable and fast unified management solution for terminal equipment, builds an efficient and real-time equipment management system, helps digitise the campus/office environment and makes campus/office management more convenient.

SECURITY
Utilise Screen lock and USB passcode protection to ensure user security and the new Clean app will clear all data and passwords used.

Technical Specifications

Display

Panel type
IPS
Display number of colours
1.073 billion colours
Number of simultaneous touchpoints
40
LED backlighting type
Direct-LED
Touchscreen
Yes

Active display area (W x H)
1895 x 1066 mm
Display technology
LED
Display diagonal
2.18 m (86″)
Display resolution
3840 x 2160 pixels
Display brightness
400 cd/m²
HD type
4K Ultra HD
Response time
8 ms
Contrast ratio (typical)
1200:1
Viewing angle, horizontal
178°
Viewing angle, vertical
178°
Pixel pitch
0.4935 x 0.4935 mm
Display diagonal (metric)
217.4 cm
Panel life
50000 h
Native aspect ratio
16:9
Horizontal scan range
30 – 135 kHz

Number of displays

Number of displays
1
Touchscreen technology
Infrared
Surface hardness
7H
Haze rate
28%
USB connector type
USB Type-C

Remote (IR) input

Remote (IR) input
1
USB port
Yes

HDMI version

HDMI version
2
RS-232C
Yes
Wi-Fi
Yes
Ethernet LAN
Yes

HDMI ports quantity

HDMI ports quantity
4

VGA (D-Sub) input ports

VGA (D-Sub) input ports
1

Ethernet LAN (RJ-45) ports

Ethernet LAN (RJ-45) ports
2
USB version
2.0/3.2 Gen 1 (3.1 Gen 1)

USB ports quantity

USB ports quantity
6

HDMI input ports quantity

HDMI input ports quantity
3

HDMI output ports quantity

HDMI output ports quantity
1

Number of built-in speakers

Number of built-in speakers
2
RMS rated power
32 W
Built-in speaker(s)
Yes

Design

Product design
Digital signage flat panel
Placement supported
Indoor
Orientation
Horizontal
Bezel width (top)
1.65 cm
Bezel width (side)
1.65 cm
Bezel width (bottom)
3.1 cm
Product colour
Black
Panel mounting interface
800 x 600 mm
VESA mounting
Yes
Positioning accuracy
1.5 mm

Performance

Purpose
Commercial
Operating hours (hours/days)
16/7
Mean time between failures (MTBF)
50000 h

Number of OSD languages

HDCP
Yes
Plug and Play
Yes
HDCP version
2.2
Windows operating systems supported
Yes
Linux operating systems supported
Yes

Power

Power consumption (off)
0.3 W
Power consumption (typical)
215 W
Power consumption (standby)
0.5 W
AC input voltage
100 – 240 V
AC input frequency
50 – 60 Hz

Computer system

Computer system
Yes
Processor cores
4
Operating system installed
Android 11
Internal memory
32 GB
Internal storage capacity
4 GB
Built-in processor
Yes
On-board graphics card model
ARM Mali-G52

Weight & dimensions

Display width
1957 mm
Display depth
100 mm
Display height
1160 mm
Display weight
58.6 kg

Packaging data

Package width
2110 mm
Package depth
225 mm
Package height
1283 mm
Package weight
75.9 kg
Quick start guide
Yes
Batteries included
Yes
Remote control included
Yes
Cables included
AC, HDMI, USB
Stylus pen
Yes

Number of stylus pens

Number of stylus pens
4
Power adapter included
Yes

Operational conditions

Storage temperature (T-T)
-20 – 60 °C

Technical details

Power supply type
Internal

OPS slot

OPS slot
1

Playback media

Playback media
1

Features

Base colour
Black
Base material
Metal

Other features

Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)

Bluetooth version

Bluetooth version
5
Bluetooth
Yes

Audio input

Audio input
1
Bluetooth Low Energy (BLE)
Yes
