Atlona Technologies HDBaseT Scaler with HDMI & Analog Audio Outputs (AT-HDVS-150-RX)

HDBaseT Scaler with HDMI and Analog Audio Outputs

The Atlona AT-HDVS-150-RX is an HDBaseT scaler receiver for HDMI transmission over category cable. It receives AV signals up to 1080p/60Hz or 1920×1200 video with embedded audio and control signals at distances up to 230 feet (70 meters). Features include balanced analog audio de-embedding, RS-232 control, and Power over Ethernet for compatible transmitting devices. The receiver offers advanced scaling capabilities including image adjustment capability and an Auto-set feature for matching incoming signals to the display’s native resolution. Designed for use with the AT-HDVS-150-TX transmitter, the transmitter/receiver pair enables auto display on/off, auto-switching, third-party control, and other features. The built-in HD video scaler works with matrix switchers to optimize source signals with different resolutions to a display’s native resolution. The AT-HDVS-RX is ideal for long distance transmission and display control in corporate or educational settings using analog and digital sources.

The HDVS-150 maintains all capabilities the HDVS series is known for and adds industry-standard Power over Ethernet for full HDBaseT certification. The HDVS-150 Series is a simple audio visual system with auto-switching for HDMI and VGA inputs, projector on/off control, analog audio de-embedding, volume control, and a scaler. Much more than an extender system, it provides a complete system for small spaces like huddle rooms and teaching spaces with 2 or 3 sources.

Features

• Long distance HDMI extension : Receives HDMI and VGA/Audio signals up to 230 ft (70m) @ 1080p over CAT6a/7 and 197 feet (60 m) @ 1080p over CAT5e/6
  Uses easy–to–integrate category cable for low–cost, reliable system installation
• Scaled HDMI output and input resolution control :Scales output video signals up to 1080p/60Hz and1920x1200; Set preferred input resolution from 800×600 to 1920×1200
  Assures compatibility of VGA and HDMI sources to the display’s native resolution
• Power over Ethernet for AT–HDVS–150–TX : Industry standard IEEE 802.3af PoE supplied by the receiver over HDBaseT
  No local AC outlet required at the AT–HDVS–150–TX switcher; saves time and integration costs
• Audio de–embedding : Provides two channel, analog audio signal on balanced captive screw connectors
  Improves AV system audio with the use of an external amplifier such as the Atlona AT–PA100–G2
• RS–232 scaler control : Image adjustments, resolution settings, and auto–set to display’s native resolution can be made from a third party control system
  Seamless integration with larger, control system–based AV systems
• RS–232 display control : Facilitates On/Off display control; Included software simplifies programming
  Eliminates need for complex control system in small AV system
• Field updatable firmware :Rear panel USB port provides an easy means for kit upgrades
  Ensures long term system return on investment
