Unilumin UTV SC162

Dimensions:

3611 x 2151 x 30.4 mm

Thickness:

30.4 mm (without wall-hung) / 52.4 mm (with wall-hung)

Planeness:

0.1 mm

Weight:

180 Kg

Material:

Die-Cast Aluminium

Border Material/Colour:

Aluminium Profile / Black

Maintenance:

Front

Installation Method:

Wall-mounting, Mobile stand (optional extra)

Display

LED Type:

COB

LED Life Time:

100000

Horizontal/Vertical Viewing Angle (degree):

H: 170°/ V: 160°

Brightness:

600 cd/m² (adjustable)

Refresh Rate:

3840 Hz

Video Frame Rate:

50/60 Hz

Processing Depth:

13 Bit

Contrast Ratio:

10000:1

Colour Temperature:

2000K~9500K

Pixel Level Brightness Calibration:

Support

Pixel Level Colour Calibration:

Support

Brightness Uniformity:

98%

Colour Uniformity:

±0.003Cx,Cy or less

Mainboard Parameters

Operating System:

Android 11.0

CPU:

Cortex A73*4+A53*4

RAM/ROM:

8GB DDR4/64GB

Interface:

SPDIF x 1, USB2.0 x 1, HDMI in x 2, USB3.0 x 3, Audio out x 1, LAN x 2

WiFi:

WiFi 5 + WiFi 6 (Dual wifi)

Bluetooth:

5.0

Remote Control:

Support

Speaker

Fixed Mode:

Built-in

Rated Power:

12Wx2

Operation Parameters

Input Voltage:

AC 100 V ~ 240 V, 50-60Hz

Standby Power Consumption:

0.8 W

Average Power Consumption:

600 W

Peak Power Consumption:

1500 W

Operating Temperature/Humidity:

-10°C ~ +45°C / 10~80% RH

Storage Temperature/Humidity:

-20°C ~ +50°C / 10~70% RH

Standard Fittings

Remote Controls

1 Included

U-disk

1 Included

Manual Vacuum Suction Cup

1 Included

Spare Parts LED Modules

2 Included

Warranty Card

1 Included

Certificate

1 Included

Instructions

1 Included
