NEC ME403U
This product is now discontinued. Please contact us for details of a replacement product
The NEC ME403U projector offers bright 4000 lumens, WUXGA resolution, and versatile connectivity. Perfect for classrooms and meeting rooms.
- 4000 Lumens Brightness (Lamp / LCD)
- WUXGA Resolution – 16:10 Aspect Ratio
- Lens Ratio 1.20-2.00 : 1
- Projector warranty: 3 Years
- Lamp warranty: 6 months or 1000 cumulative hours
- 3.5 KG
- Volume discounts available
Quick Links
Projectorpoint Opinion
The NEC ME403U features a bright 4000 lumens and native widescreen high definition WUXGA resolution (1920 x 1200 pixels, 16:10 aspect ratio) as well as extensive connectivity including dual HDMI inputs.
A great first time or replacement projector, the ME403U boasts a strong 1.2-2:1 lens ratio with 1.6x optical zoom providing the user with immense flexibility in where the projector can be placed in relation to the distance to screen.
LCD display technology ensure rich, colour accurate images. The NEC ME403U is a popular choice for meeting or training rooms.
Manufacturer Overview
Description
Bringing exceptional long lamp life performance to the classroom and small meeting room, for classic presentation usage the new generation ME series delivers standard throw projection that’s anything but standard. Keeping operational costs to a minimum with no lamp costs to factor in, users enjoy up to 20,000 hours of trouble-free projection and no lamp replacement efforts.
A large 1.6x optical zoom brings impressive integration flexibility making it easier to position the projector in the room, whilst existing ceiling mount locations can be utilised without the need to reposition.
Benefits
Minimized cost of ownership – due to long lamp life and filter exchange intervals.
Versatile and mobile – compact and light-weight with HDMI and integrated 16W speaker.
Display content that demands attention – with WUXGA resolution and superb brightness levels and colour ranges, your viewers will enjoy an outstanding visual experience.
Future-proof input management – thanks to 4K@30 Hz input processing.
Technical Specifications
- Projector native resolution
- WUXGA (1920×1200)
- Native aspect ratio
- 16:10
- Screen size compatibility
- 762 – 7620 mm (30 – 300″)
- Projection distance
- 0.75 – 12.88 m
- Contrast ratio (typical)
- 16000:1
- Zoom capability
- Yes
- Projector brightness (economic mode)
- 3000 ANSI lumens
- Keystone correction, vertical
- -30 – 30°
- Keystone correction, horizontal
- -30 – 30°
- Projection technology
- 3LCD
- Projector brightness
- 4000 ANSI lumens
- Zoom type
- Manual
Lamps
- Lamp power (economic mode)
- 151 W
- Lamp power
- 225 W
- Light source type
- Lamp
- Service life of light source
- 10000 h
- Service life of light source (economic mode)
- 20000 h
Lens system
- Focus
- Manual
- Focal length range
- 17.2–27.7
- Aperture range (F-F)
- 1.5 – 2.08
Video
- Video colour modes
- DICOM simulation mode
- Analog signal format system
- NTSC, PAL, PAL 60, SECAM
- Full HD
- Yes
- Supported graphics resolutions
- 1920 x 1200 (WUXGA), 3840 x 2160
- Built-in speaker(s)
- Yes
Number of built-in speakers
- Number of built-in speakers
- 1
- RMS rated power
- 16 W
USB 2.0 Type-B ports quantity
- USB 2.0 Type-B ports quantity
- 1
VGA (D-Sub) ports quantity
- VGA (D-Sub) ports quantity
- 2
HDMI ports quantity
- HDMI ports quantity
- 2
Ethernet LAN (RJ-45) ports
- Ethernet LAN (RJ-45) ports
- 1
USB 2.0 ports quantity
- USB 2.0 ports quantity
- 1
Audio (L/R) in
- Audio (L/R) in
- 1
Audio (L/R) out
- Audio (L/R) out
- 1
- Serial interface type
- RS-232
- DVI port
- No
Network
- Ethernet LAN
- Yes
Sound emission
- Noise level
- 37 dB
- Noise level (economic mode)
- 29 dB
Technical details
- Product colour
- White
- Wall colour correction
- Yes
Performance
- Password protection
- Yes
Design
- Product type
- Standard throw projector
- Cable lock slot type
- Kensington
- Cable lock slot
- Yes
Power
- AC input voltage
- 100 – 240 V
- AC input frequency
- 50 – 60 Hz
- Power consumption (max)
- 295 W
- Auto power off
- Yes
- Power consumption (economy mode)
- 207 W
Operational conditions
- Storage temperature (T-T)
- -10 – 50 °C
Weight & dimensions
- Weight
- 3.5 kg
- Width
- 345 mm
- Depth
- 261 mm
- Height
- 104.6 mm
Packaging content
- Remote control included
- Yes
- Batteries included
- Yes
