VISION AV-1800 Stereo Amplifier

The Vision AV-1800 is compact, and has a simple interface with just two dials which are turned to adjust and pushed to switch. It has a selection of inputs – including Bluetooth and a microphone input, making it suitable for meeting rooms, small auditoriums, lecture theatres, school halls, and small churches.

Bluetooth : The amplifier can automatically switch to the Bluetooth source when it is paired. Bluetooth can be renamed and the pin changed by connecting to a PC (see software link below).

Microphone Input : It uses a professional XLR connector and the input is “balanced” to eliminate electro-magnetic noise induced on long cables. The microphone input has “Phantom Power” – a voltage which is required by condenser-type microphones such as lectern microphones.

RS232 : It can be controlled by a control device such as Techconnect Control via IR or RS-232. It also comes with an IR remote control gives the user bass and treble adjustment and direct input selection.

D-Class : An efficient Digital-class amplifier chip dramatically reduces power consumption especially at rest.

3 x Stereo Inputs : Three stereo inputs accept input from a variety of sources such as computers (via the headphone jack), tablets or phones. 2 of the inputs are via 2-phono (RCA) connectors on the rear panel. Input 3 is via a 3.5mm Minijack connector, and is duplicated on the front and rear panels for easy access.

Line output – A line-level pre-output on the rear panel bypasses the internal amplifier. It would connect to a larger amplifier or powered loudspeakers. It is post-mix, which means any volume adjustment made on the front panel affects the output level.

Auto Standby – If the amplifier senses no input it will automatically go into standby mode. When it senses input it will reactivate. Auto-standby can be disabled.

Mounting Options – Optional mounting hardware is included to allow cable-tying either to a projector ceiling pole, or into a rack.

Specifications

AMPLIFIER DIMENSIONS: 253 x 253 x 45 mm / 9.96″ x 9.96″ x 1.77″ (wide x deep x tall) not including dials and connectors

CARTON DIMENSIONS: 415 x 230 x 80 mm / 16.34″ x 9.06″ x 3.15″

AMPLIFIER WEIGHT: 2.0 kg / 4.4 lb

PACKAGED WEIGHT: 2.4 kg / 5.3 lb

COLOUR: White

INPUTS
3 x Stereo inputs via 2-phono (RCA) connectors / 1 x 3.5mm (1/4″) minijack
1 x Bluetooth input
1 x Microphone inputs via balanced XLR

OUTPUTS
1 x Stereo Line-level output via phono connectors (post mix)

TECHNICAL DETAILS
2 x 50w @ 8 ohms
Total Harmonic Distortion <1%
Frequency response (line in): 20Hz~20kHz
Signal to noise ratio (line in): 75dB
Rating input level/Impedance: line in 800~900mV/47kohms
Operating temperature range: 0 to +40°C (32 to +104 °F)
Power consumption (rating condition): <=125W
Phantom Power Disable: via internal jumper
Phantom Power: 21V

ACCESSORIES INCLUDED
1 x 2-phono to 2-phono cable 2m long
1 x 3.5mm to 3.5mm minijack cable 2m long
2 x Unshielded Speaker Cable 5m long
1 x UK C7 figure-8 power cable 1.8 m long
1 x EU C7 figure-8 power cable 1.8 m long
1 x AU C7 figure-8 power cable 1.8 m long
1 x US C7 figure-8 power cable 1.8 m long
1 x Remote Control (Battery included: CR2025 3V Li-Mn)
1 x Rack ears
1 x Ceiling pole and wall brackets

POWER SUPPLY: 100~240V Internal Power Supply

WARRANTY: Lifetime return-to-base
